Jul. 01, 2025
Metal silicon induction furnace, especially medium frequency melting furnace, is mainly used for melting metal silicon. It uses the principle of induction heating to heat the high-purity graphite crucible through a magnetic field, and then heats and melts the metal silicon.
This induction melting furnace is usually composed of a furnace body, a power control cabinet, a capacitor rack and a hydraulic station. It can work continuously for 24 hours and has self-test and water leakage alarm functions.
Induction furnaces are also used to smelt other metals, such as steel, copper, aluminum, etc.
Induction furnaces are mainly used for metal melting, especially for melting silicon-aluminum alloys. It is suitable for industries such as machinery industry, construction, and civil life.
Induction melting furnaces are divided into cored and coreless types. Cored induction furnaces are often used for smelting and heat preservation of cast iron, while coreless induction furnace are of power frequency, triple frequency and medium frequency types.
Refractory materials, such as refractory clay bricks, high alumina bricks, silica bricks, magnesium bricks, etc., are used to build melting furnaces to withstand high temperatures and various physical and chemical effects.
Metal silicon induction melting furnace, also known as coreless induction furnaces. The coreless furnace heated by electromagnetic induction is suitable for metal smelting and alloy preparation, and non-metallic silicon raw material production.
Metallurgy: silicon aluminum alloy, ferroalloy, carbon steel/ductile iron smelting (automobile, aviation, construction).
Electricity: casting and maintenance of heat-resistant steel parts of power stations.
Chemical industry: smelting of metal catalysts and corrosion-resistant alloys.
Shipping: smelting and heat treatment of marine steel and copper alloys.
Laboratory: small batch smelting of active metals such as titanium, aluminum, and zirconium (inert protection required).
Advantages: high efficiency, precise temperature control, clean (compared to traditional fuel furnaces), and adaptable to multiple metals.
Characteristics of smelting materials:
Different materials have different requirements for the refractory materials, frequency, power, etc. of the induction furnace.
Smelting scale:
The capacity and power of the induction melting furnace need to be selected according to the smelting scale.
Smelting process:
Continuous smelting and discontinuous smelting also have different requirements for induction furnaces.
Cost:
The cost of the metal silicon induction furnace needs to be evaluated according to demand
