What is the Specific Energy Conversion Process of Induction Heating?

Metallic silicon (industrial silicon) smelting furnaces typically employ submerged arc furnaces, the main body of which is a resistance arc furnace. However, induction heating principles are also used in silicon smelting technologies (such as some experimental or specialty silicon production devices). Today, we'll understand the energy conversion involved in using an induction furnace.

Energy Conversion in Induction Furnace Silicon Smelting

These devices (such as certain vacuum induction furnaces or induction refining furnaces) are typically used to melt, purify, or prepare specialty silicon from pre-refined silicon, rather than directly smelting from ore. The energy conversion is a typical induction heating process in a smelting furnace.

The specific energy conversion process is as follows:

1. Electrical Energy → High-Frequency Magnetic Field Energy

A medium-frequency or high-frequency AC power supply powers an induction coil surrounding the crucible, generating a rapidly changing alternating magnetic field.

2. Magnetic Field Energy → Eddy Current Energy

The magnetic field penetrates the refractory crucible and acts on the conductive solid/molten silicon material inside.

According to Faraday's law of electromagnetic induction, the changing magnetic field induces closed eddy currents within the silicon material.

3. Eddy Current Energy → Joule Heating (Thermal Energy)

Silicon itself is a semiconductor, and its conductivity increases after melting. Eddy currents flow in the resistive silicon molten material, generating enormous Joule heat, causing the silicon material itself to heat up and melt.

Simultaneously, the alternating magnetic field also induces hysteresis losses (significant for magnetic materials, but very small for silicon) and dielectric losses (contributing to some materials at high frequencies) within the silicon molecules and atoms. However, these account for a very small percentage in silicon induction heating furnaces; eddy current heating is the absolutely dominant mechanism.

4. Thermal Energy → Melting and Refining

The generated heat is used to:

Melt the silicon material, forming a molten pool.

Maintain high temperatures to promote the volatilization of impurities (such as phosphorus, aluminum, calcium, etc.).

Through the stirring effect of electromagnetic force (the interaction of eddy currents and magnetic field generates Lorentz force), the molten pool is automatically stirred, resulting in uniform composition and temperature, accelerating impurity migration and gas removal.

Energy Flow Summary for Induction Heating Furnaces

Grid AC power → Variable frequency power supply (converted to medium/high frequency) → Induction coil (alternating current)

↓

High-intensity alternating magnetic field → Penetrates the crucible and acts on the silicon material

↓

Eddy currents are generated inside the silicon material → Eddy currents generate Joule heat due to the resistance of silicon

↓

Silicon material heats up, melts, and overheats → Provides the heat energy required for melting and refining, accompanied by electromagnetic stirring

As can be seen from the above, if a silicon smelting furnace uses induction heating technology, its energy conversion strictly follows the classic induction heating path of "electrical energy → magnetic energy → eddy current electrical energy → heat energy". Its characteristics include non-contact operation, internal heat source, and self-stirring, and it is mostly used for refining and the preparation of special silicon.
